FRANSGARD GRADER BLADES

European Manufactured
Quality Grader Blades

Fransgard is a family-owned business founded in Denmark more than 50 years ago, who specialise in producing affordable high quality Grader Blades, as well as a range of small field and road maintenance equipment. Fransgard manufacture their equipment in a state-of-the-art 10,000m2 factory and focus on delivering practical and user-friendly solutions for farmers all around the world.

Trailed GT-350AUS Grader Blade

The new 3.5m GT-AUS Trailed model from Fransgard sets a new standard for professional blades.



The unique +/- 20° horizontal tilt capability sets the blade apart from its competitors, enabling the user to follow and create the desired shape of the road or track being maintained. The gas accumulation tanks and quality rear tyres make for an incredibly smooth ride and helps to deal with variation of soil compaction.

For an affordable way to re-model your tracks, look no further than the GT-300AUS.

Specifications:

  • Work width: 350 cm

  • Scraper height: 70 cm

  • Offset adjustment mechanical right/left: 60 cm

  • Hydraulic turnable blade: 60°

  • Hydraulic horizontal setting: +/- 20°

  • Hydraulic output: 4 double

  • Turnable reinforced steel Hardox 500: Standard

  • Wheels Standard

  • Side plate: Possible

  • Weight: 1270 kg

3-Point Linkage DKH Grader Blade

The DKH model is the 3-point linkage version of the GT-350AUS above.

It has the same sturdy 70cm high blade with replaceable wear plates and hydraulic horizontal tilt capable of +/- 20°. The adjustable 360° swivel guide wheels help to create a smooth and definitive cut, and also assist when you wish to use the back side of the blade.

The gas accumulator system is optional on this machine (does not come as standard).


Specifications:

  • Work width: 250/275/300 cm

  • Scraper height: 70 cm

  • Offset adjustment mechanical right/left: 55/60 cm

  • Hydraulic turnable blade: 300°

  • Hydraulic horizontal setting: +/- 20°

  • Hydraulic output: 3 double

  • Turnable reinforced steel Hardox 500: Standard

  • Wheels Standard

  • Side plate: Possible

  • Weight: 940/955/975 kg

3-Point Linkage HNZ Grader Blade

The HNZ range is the little brother of the DKH above.

It still boasts a 60cm high blade with replaceable wear plates, however the +/- 20° horizontal tilt angle is manually adjusted rather than hydraulic.

With 250cm and 275cm width options, this is an extremely economical blade which will stand the test of time.
